TP-LINK 5GHZ INDOOR/OUTDOOR ACCESS POINT

TP-Link Omada EAP211-Bridge KIT 5.0GHz 867Mbps Wireless Bridge Indoor/Outdoor Access Point Discreet Design. Dedicated Room Wi-Fi. The TP-Link EAP115-Wall delivers stable 300Mbps 2.4GHz Wi-Fi in a compact wall-plate form factor, ideal for hotels, offices and residential deployments. Designed to fit standard EU wall-boxes, it provides seamless in-room coverage without visible clutter. With 802.3af PoE support, centralised management and enterprise-grade security, it?s a smart solution for scalable, room-by-room wireless networking.

Key features:
• 867Mbps 802.11ac Performance – Delivers up to 867Mbps on 5.0GHz for high-speed wireless backhaul and connectivity • Long-Range Wireless Transmission – Ideal for outdoor links up to 1km • Auto-Pairing With Agile LEDs – Enables fast deployment and clear signal alignment • 3× Gigabit Ethernet Ports – Supports multiple high-speed IP camera connections • Omada SDN Supported – Enables remote and centralised cloud management • IP65 Weatherproof With 6kV Lightning Protection – Built for reliable all-weather outdoor operation • Passive PoE Included – Flexible deployment with simplified power and data installation SPECIFICATIONS HARDWARE FEATURES INTERFACE • 3× Gigabit Ethernet Ports BUTTON • Reset POWER SUPPLY • 12V DC • 24V Passive PoE (Adapter Included) POWER CONSUMPTION • 11.5W DIMENSIONS (W × D × H) • 79 × 60 × 224mm ANTENNA • Internal 2× Dual-Polarised Directional MIMO Antennas • 5.0GHz: 7dBi • Beamwidth: 70° Horizontal, 70° Vertical WEATHERPROOF ENCLOSURE • IP65 MOUNTING • Pole Mounting (Accessories Included) WIRELESS FEATURES COVERAGE • Up to 1000m WIRELESS STANDARDS • IEEE 802.11a/b/g/n/ac FREQUENCY • 5.0GHz SIGNAL RATE • up to 867Mbps WIRELESS FUNCTIONS • Mesh • 5G 2×2 MU-MIMO (DL) • Load Balance • Seamless Roaming (802.11r) • Beamforming • Airtime Fairness • Up to 8 SSIDs • Wireless Statistics • Wireless Schedule • Reboot Schedule • RADIUS Accounting • MAC Authentication • Static IP / Dynamic IP WIRELESS SECURITY • VLAN Support • Access Control • Rogue AP Detection • Captive Portal Authentication • Maximum MAC Filter Entries: 4,000 • WPA-Personal / Enterprise • WPA2-Personal / Enterprise TRANSMISSION POWER CE • <23dBm (5.0GHz Band 1/2, EIRP) • <30dBm (5.0GHz Band 3, EIRP) FCC • <22dBm (5.0GHz Band 1/4) MANAGEMENT • Omada App • Restore and Backup • Firmware Update via Web • NTP CENTRALISED MANAGEMENT • Omada Hardware Controller (OC300, OC200) • Omada Software Controller • Omada Cloud-Based Controller CLOUD ACCESS • Yes (Requires OC300, OC200, Omada Software Controller or Cloud-Based Controller) • LED On/Off Control • Management MAC Access Control • SNMP v1/v2c/v3 • SSH • Web-Based Management CERTIFICATION • CE • FCC • RoHS ENVIRONMENT • Operating Temperature: -40~70°C • Storage Temperature: -40~70°C • Operating Humidity: 10~90% Non-Condensing • Storage Humidity: 5~90% Non-Condensing
